| Accessories |

BCD Thumbwheel Switches
| |
Description |
|
| |
The TWTB Series is sealed internally to protect against dust,
dirt, and moisture. The TWSTB thumbwheel switch is sealed
against dust and dirt only. A plastic window covers each
digit. Each .500" wide switch is sized for comfortable
operation while saving space. They accept voltages up to 120
VAC. They are also available with diode isolation for use with
multiplexing. Screw mounting hardware and screw terminal block
connections are standard.
|

BCD
Rotary Switches
| Features |
Description |
- Withstands
hose down when enclosed by
NEMA 4X / IP65 housing
- Nontoxic
exposed parts
- BCD
output with or without diode blocking
- Large
knob, easy to operate
- Large
number display
- Heavy
duty
|
The KEP rotary switches are available in 1 through 6 decades.
They are heavy duty switches numbered 0 through 9, and meets
NEMA 4X/IP65 ratings. The BCD outputs, complete with blocking
diode, are suitable for input connection to almost any
programmable controller.
The rotary switches are used to input production count,
correction factors, times, etc. into registers. Large numbers,
stainless steel shafts, large knobs and Buna-N seals permit
use in a variety of environments.
The switches are not affected by hose down, even with most
caustic additives.
|

Incremental
Shaft Encoder
| Features |
Description |
- Low
Cost
- Short
Circuit Resistant Outputs
- Low
Power Consumption
- Shock
Resistant
|
|

Incremental
Shaft Encoder
| Features |
Description |
- Low
Cost
- Short
Circuit Resistant Outputs
- Rugged
Design to Industry Standard
- Low
Power Consumption
- Shock
Resistant
|
|
Inductive
Proximity Sensors
| Features |
Description |
- CE
Approved
- Low
Cost
- Non-contact
Sensing of Any Metal
- No
Magnets Needed
- Low
Power Consumption
- Shock
Resistant
|
|
Photoelectric
Sensors
| Features |
Description |
- Low
Cost
- Non-contact
Sensing
- Various
Sensing Types
- Low
Power Consumption
- Shock
Resistant
|
The
PD Series photoelectric sensors offer superior optical
performance in a miniature 18mm package. Designed specifically
for a wide variety of applications, including food processing,
packaging, and materials handling. Their miniature size makes
it easy to design into any system.
The PD Series provides flawless
operation in the harshest environments. Rated NEMA 4, 6, and
13, the PD Series keeps working in wet and high-pressure
washdown situations even under water. The PD Series is highly
immune to extreme shock and vibration, and passes the NEMA ICS
1-109 showering arc test. Even walkie-talkies won't interfere
with it's performance.
PD Series sensors are available
in 10-30VDC thru-beam reflex, and proximity configurations.
Infrared, visible-beam, and polarized models are available, as
is a complete line of fiber optic cables. Easy alignment is
provided by a variable intensity indicator (patents pending)
on all models, and by an additional forward-looking alignment
indicator on thru-beam models.
The unique "round and
square" profile makes installation easy. It can be
screwed into standard 18mm threaded brackets. Bulkhead mounts
are mounted flush against any surface. Electrical connections
are made via an all purpose cable.
|

Desktop
/ Handheld
Serial Printer
| Features |
Description |
- Dot
Matrix Printer
- Uses
Standard 2.25" Plain Paper Roll
- 24 or
40 Column Printing
- Standard
Epson tm Ribbon
- Internal
2KB Buffer
- RS232
With Selectable Baud Rate
- Will
Operate for 2 hours on internal Batteries for Hand Held
Applications.
|
The P1000 Printer is a top
quality, impact dot matrix micro printer. It is small., light
weight, and low in cost, but extremely powerful in
performance. This model is portable and designed for
applications where regular desktop printers are unnecessary
and space is limited. The P1000 is ideal for many uses such as
logging data from KEP instruments, direct recording
measurements from digital hand held tools, or electronic
scales, remote messaging and more!
|

Time
and Date Clock
| Features |
Description |
- Month,
date, hour, minute, and second Information to PLC
- Crystal
time base or line frequency time base
- 8
wire I/0 connection
- Automatic
sensing of 50, 60 Hz or DC supply
- Field
programmable 12 or 24 hour display
- AM
and PM indicators
- NEMA
4X/IP65 Front
|
The PC/C is a low cost, accurate
time and date clock with a PLC compatible interface requiring
only 8 wire connections for I/O. The internal battery standby
system will operate the PC/C for up to six months without
external power. Available in either AC or DC supply versions,
accuracy of better than +.005% can be attained. When an
accurate, non-interruptible time and date source is needed for
report generators or other applications, the PC/C is the ideal
solution.
The PC/C is a microprocessor
based crystal controlled time and date clock. The PC/C
displays hours, minutes, month and date on large, brilliant
.55" high red-orange LED’s. In addition, the PC/C will
output, on demand to the PLC, hours, minutes and seconds as
well as the month and date. The unique interface allows easy
connection to almost any PLC via standard 12 to 24 Volt I/O
ports or 12 Volt CMOS interface.
|
Signal
Conditioners
| Features |
Description |
- Two
Year Warranty
- Loop
Powered (SC-FI & SC-II only)
- Pulse,
Contact Closure or Magnetic Pickup
Inputs (SC-FI & SC-FF only)
- Various
Mounting Styles
- LED
Indicators
|
The SC-FI is a two wire
frequency to analog converter that converts a pulse rate input
into a 4-20 mA output signal proportional to frequency or
rate. The input pulse rate is amplified and filtered by the
input signal conditioning circuitry. Two forms of input signal
conditioning are provided, one for magnetic pickups, the other
being an isolated pulse input. The amplified frequency signal
is then converted to an analog signal using a precision
frequency to analog converter. The output stage derives its
power from the output current loop. The output stage converts
the analog input signal into the desired output range.
Multi-turn potentiometers provide for the necessary trimming
of span and zero.
|
Smart
Interface Cables for KEP
Operator Interfaces
|
|
|
